Vessel’s Specification
Ship Name:
***
IMO No.:
***
Ship Type:
AHTS
Class:
CCS
Built Place:
China
Navigation Area:
A1+A2+A3
Flag:
China
Built Date:
2008.12
Loa:
59.25M
Breadth:
14.95M
Depth:
6.1M
Draft:
4.95M
DWT:
1425T
GT:
1678T
NT:
504T
Deck Area:
340㎡
Deck Loading:
7.5t/㎡
Capstan:
10T
Tugger:
20T
Bollard pull:
63.77T
Liquid Mud/Brine:
419m³
ME Brand:
Caterpillar
Main Engine Model:
3516B-HD
ME Power:
3840kw
RPM:
1600R/Min
Speed:
10KN
Aux. Engine Brand:
Caterpillar
Aux. Engine No.:
3
Aux. Engine Power:
315kw
Oil Consumption:
9T/D
Main Engine No:
Double
Anchor Handling:
yes
Fire Fighting Level:
LEVEL ONE
Propulsion type:
CONTROLLABLE PITCH
DP:
no
NOx emission standard of diesel engine:
Tier II
Release Date:
2025.05.08
Certificates, Drawings
Certificate of Inspection:
yes
General Arrangement Plan (GA):
yes
Certificate of Ship Ownership:
No
Certificate of Registry:
No
Ship Equipment List:
yes
Remarks
The vessel is under way.
